Izdb Vortical Self-Priming Solar Water Pump

Product Description



1.Vortical Irrigation pump
2. Positive Cooperation
3. Strict Delivery Time
4. Wide Application

Product Description




IZDB/ WZB series self-sucking pump are constituted with clean water pump, Non-return Valve and air-water separation room which located on the upside of the pump body. During operating, no need to use foot valve ( The pump is supplied with check valve on the suction side so that no foot valve is required ), what you should do is just to leave some water in the pump body, after a few minutes running, the water will be sucked out relying on the pump body itself's effect.



  • Ideal equipments for household well water pumping.
  • Special for domestic and industrial applications such as water supply for recirculation in air conditioners and refrigerators, industrial water uses in general, and the automatic distribution of water from surge tanks, watering gardens, lifting water from tanks or wells down to 9m depth.

Operating limits

  • Max. suction:8m
  • Max. medium temperature+40°C
  • Max. ambient temperature+40°C
  • Clean water, non-aggresive liquid
  • The grain diameter of the solids in the water is no bigger than 0.2mm

Material and working limits

  • 100% copper wire
  • Pump body: Cast iron
  • Motor housing: Aluminum
  • Impeller: Brass
  • Mechanical seal: Graphite&Ceramic
  • Shaft:45#steel
  • Insulation class: F
  • Protection class: IP44

Packing & Delivery

  • Packing: 1 pc/ctn
  • Packing design: standard export carton or customer's design
  • Delivery: 30 days after receiving deposit
  • Delivery port: Ningbo

WARRANTY: 1 YEAR ( according to our general sales conditions)
