Hot Sale Jet-80L-0.55kw Self-Priming Centrifugal Solar Water Pump

Specifications

1. 100% copper wire
2. Competitive price
3. Hgih quality
4. Warranty: 1 year


Application

The Jet Self-Priming Pump combine functions and advantages of Centrifugal Pump and self-priming pump, It is suitable for pumping clean water without impurities and non-corrosive liquid. The major advantages of this pump are high discharge head, high suction head, high efficiency, and the self-priming time is quite short. Therefore, it is widely applied for irrigating garden, farmland and supply water to high-rise buildings. In addition, the pump must be installed in enclosed place or keep it away from inclement weather.

Performance

• High heads with respects to power requirements
• Flat operating and power absorption curves, giving moderate curve variations with respect to large variations in deliver demand
• High tolerance of the presence of entrained air in the fluid to be pumped

Operating limits

• Max. suction:9m
• Max. medium temperature+40°C
• Max. ambient temperature+40°C
• Max. pressure: 6 bar
• Transport medium: PH 6-8.5

Material and working limits

• 100% copper wire
• Pump body: Cast iron
• Motor housing: Aluminum
• Impeller: PPO
• Front cover: Aluminum
• Mechanical seal: Ceramic &Graphite
• Shaft: 45#steel/stainless steel
• Insulation class: B
• Protection class: IP44

Packing & Delivery

• Packing: 1 pc/ctn
• Packing design: standard export carton or customer's design
• Delivery: 30 days after receiving deposit
• Delivery port: Ningbo

WARRANTY: 1 YEAR ( according to our general sales conditions)
