High Quality Jet Pump, Self-Priming Pump, Water Pump
Product Description
High Quality JET Pump, Self-Priming Pump, Water Pump
Application
The Jet Self-Priming Pump combine functions and advantages of Centrifugal Pump and self-priming pump, It is suitable for pumping clean water without impurities and non-corrosive liquid. The major advantages of this pump are high discharge head, high suction head, high efficiency, and the self-priming time is quite short. Therefore, it is widely applied for irrigating garden, farmland and supply water to high-rise buildings. In addition, the pump must be installed in enclosed place or keep it away from inclement weather.
Operating limits
Max. Suction: 9m
Max. Medium temperature+40
Max. Ambient temperature+40
Max. Pressure: 6 bar
Transport medium: PH 6-8.5
Material and working limits
Pump body: S. S
Motor housing: Aluminum
Impeller: Brass
Motor wire: Copper
Mechanical seal: Ceramic &Graphite
Shaft: 45#steel/stainless steel
Insulation class: B
Protection class: IP44
Application
The Jet Self-Priming Pump combine functions and advantages of Centrifugal Pump and self-priming pump, It is suitable for pumping clean water without impurities and non-corrosive liquid. The major advantages of this pump are high discharge head, high suction head, high efficiency, and the self-priming time is quite short. Therefore, it is widely applied for irrigating garden, farmland and supply water to high-rise buildings. In addition, the pump must be installed in enclosed place or keep it away from inclement weather.
Operating limits
Max. Suction: 9m
Max. Medium temperature+40
Max. Ambient temperature+40
Max. Pressure: 6 bar
Transport medium: PH 6-8.5
Material and working limits
Pump body: S. S
Motor housing: Aluminum
Impeller: Brass
Motor wire: Copper
Mechanical seal: Ceramic &Graphite
Shaft: 45#steel/stainless steel
Insulation class: B
Protection class: IP44
| MODEL | POWER (kw) | INLET/OUTLET (Inch) | MAX. FLOW (l/min) | MAX.HEAD (m) | G.W. (kg) | DIMENSION (mm) | 20GP (pcs) |
|---|---|---|---|---|---|---|---|
| DP255 | 0.55 | 1.25"x1" | 30 | 30 | 16.5 | 430×300×230 | 944 |
| DP370 | 0.75 | 1.25"x1" | 40 | 40 | 17 | 430×300×230 | 944 |
| DP505 | 1.1 | 1.25"x1" | 50 | 50 | 31 | 530×250×300 | 704 |
