Self-Priming Jet Pump, Garden Pump, Water Pump, Dp255
Product Description
Self-Priming Jet Pump with High Quality, Clean Water Pump
Application
The Jet Self-Priming Pump combine functions and advantages of Centrifugal Pump and self-priming pump, It is suitable for pumping clean water without impurities and non-corrosive liquid. The major advantages of this pump are high discharge head, high suction head, high efficiency, and the self-priming time is quite short. Therefore, it is widely applied for irrigating garden, farmland and supply water to high-rise buildings. In addition, the pump must be installed in enclosed place or keep it away from inclement weather.
Operating limits
Max. Suction: 9m
Max. Medium temperature+40
Max. Ambient temperature+40
Max. Pressure: 6 bar
Transport medium: PH 6-8.5
Material and working limits
Pump body: S. S
Motor housing: Aluminum
Impeller: Brass
Motor wire: Copper
Mechanical seal: Ceramic &Graphite
Shaft: 45#steel/stainless steel
Insulation class: B
Protection class: IP44
Application
The Jet Self-Priming Pump combine functions and advantages of Centrifugal Pump and self-priming pump, It is suitable for pumping clean water without impurities and non-corrosive liquid. The major advantages of this pump are high discharge head, high suction head, high efficiency, and the self-priming time is quite short. Therefore, it is widely applied for irrigating garden, farmland and supply water to high-rise buildings. In addition, the pump must be installed in enclosed place or keep it away from inclement weather.
Operating limits
Max. Suction: 9m
Max. Medium temperature+40
Max. Ambient temperature+40
Max. Pressure: 6 bar
Transport medium: PH 6-8.5
Material and working limits
Pump body: S. S
Motor housing: Aluminum
Impeller: Brass
Motor wire: Copper
Mechanical seal: Ceramic &Graphite
Shaft: 45#steel/stainless steel
Insulation class: B
Protection class: IP44
| MODEL | POWER (kw) | INLET/OUTLET (Inch) | MAX. FLOW (l/min) | MAX.HEAD (m) | G.W. (kg) | DIMENSION (mm) | 20GP (pcs) |
|---|---|---|---|---|---|---|---|
| DP255A | 0.55 | 1.25"x1" | 25 | 60 | 19 | 423×288×245 | 938 |
| DP370A | 0.75 | 1.25"x1" | 28 | 80 | 19 | 423×288×245 | 938 |
