Water Pump, Submersible Pump, Qdx Series

Product Description

Application
Q(D)X series Submersible Pump consist of pump, seal and motor, and equipmented with protection apparatus, It is designed for clean water, widely used for drawing water from well, farm irrigation, garden, building construction, breeding industry, and daily life. Moreover, it has small volume and light weight, more easy to use.

Operating limits

  • Max. medium temperature+40°C
  • Max. ambient temperature+40°C
  • Submersion depth:5m

Material and working limits

  • Pump body: Cast iron
  • Motor housing: Aluminum
  • Impeller: Aluminum
  • Motor wire:copper
  • Shaft: 45#steel
  • Insulation class: F
  • Protection class: IP68

Packing & Delivery

  • Packing: 1 pc/ctn
  • Packing design: standard export carton or customer's design
  • Delivery: 30 days after receiving deposit
  • Delivery port: Ningbo

WARRANTY: 1 YEAR ( according to our general sales conditions)




Model Power Q.RatedH.RatedInlet/OutletG.W.Packing dimension20GP
[Kw][HP][m³/h][m][inch][kg][mm][pcs]
QDX1.5-12-0.25F0.250.331.5121"6.1380×160×1852500
QDX1.5-17-0.37F0.370.51.5171"7.6380×160×1852500
QDX1.5-25-0.55F0.550.751.5251"9.8390×180×2002000
QDX3-18-0.55F0.550.753181.25"10.5395×185×2201750
QDX10-12-0.55F0.550.7510121.5"11395×185×2201750
QDX15-7-0.55F0.550.751572"11.5400×185×2201700
QDX1.5-32-0.75F0.7511.5321"12410×195×2201500
QDX3.24-0.75F0.7513241.25"12410×195×2201500
QDX8-18-0.75F0.7517181.5"11.8410×195×2201600
QDX10-16-0.75F0.75110162''11.8410×195×2201600
QDX15-10-0.75F0.75115102.5''12410×195×2201500
QDX30-6-0.75F0.7513063"12415×195×2251500
QDX3-35-1.1F1.11.54073"13.3455×205×210

Water Pump, Submersible Pump, Qdx SeriesWater Pump, Submersible Pump, Qdx SeriesWater Pump, Submersible Pump, Qdx Series
