Peripheral Clean Water Pump/ Vortex Pump

Product Description

QB series Peripheral Water Pump

Application

  • They are recommended for pumping clean water without abrasive particles and liquids that are non-corrosive
  • For domestic use and sprinkling irrigation for garden as well as supplying water to hotel, villa and high building
  • Must be installed in enclosed place or keep it away from inclement weather

Performance

  • High heads with respect to power requiremnets
  • Stable operating curves, with small variations in delivery rater with respect to large variations in the pressure demand
  • High tolerance of the presence of entrained air in the liquid being pumped

Operating limits

  • Max. suction:8m
  • Max. medium temperature+40°C
  • Max. ambient temperature+40°C
  • Max. pressure: 6 bar

Material and working limits


  • 100% copper wire
  • Pump body: Cast iron
  • Motor housing: Aluminum
  • Impeller: Brass
  • Front cover: Aluminum
  • Mechanical seal:
  • Shaft:45#steel/ stainless steel
  • Insulation class: F
  • Protection class: IP44
Packing& Delivery
  • Packing: 6 pcs/ctn
  • Packing design: standard export carton or customer's design
  • Delivery: 30 days after receiving deposit
  • Delivery port: Ningbo

Peripheral Clean Water Pump/ Vortex PumpPeripheral Clean Water Pump/ Vortex Pump
Peripheral Clean Water Pump/ Vortex Pump



MODEL POWER
(KW)
INLET/OUTLET
(Inch)
Q.MAX
(l/min)
RATED-HEAD
(m)
G.W.
(kg)
DIMENSION
(mm)
20GP
(pcs)
IDB-35 0.37 1"x1"  35  35 6 275×150×170   3992
IDB-45 0.55 1"x1" 40  50 9.5 345×185×205  2140
IDB-65 0.75 1"x1" 45  55 11.2 345×185×205  2140

Contact us if you need more details on Vortex Pump. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Water Pump、Peripheral Pump. If these products fail to match your need, please contact us and we would like to provide relevant information.
